PID Temperature Controllers ITC-106VH Kit

INKBIRD’s PID Temperature Controllers ITC-106VH Kit is a compact, panel‑mount PID thermostat for precise temperature regulation. The kit pairs the ITC‑106VH controller with a K‑type thermocouple (0–400°C) and optional 25A/40A SSR and heat sink. Dual LED displays show process (PV) and set (SV) temperatures simultaneously, and auto‑tuning simplifies loop setup. The controller runs on AC 100–240 V, fits a DIN 48×48 mm cutout (45×45 mm panel hole), samples at 0.5 s, and offers ±0.2% FS display accuracy. Operating conditions are −10 to 55°C, 35–85% RH; data storage is rated for about 10 years. The ITC‑106VH supports multiple sensor types (including K and PT100), but this kit ships with a K‑type probe and, depending on variant, an SSR and heat sink.
